BRAKE DRUMS

    • The performance and durability standards expected by manufacturers and millions of customers are met by manufactured brake drums.

    • To satisfy the demands of drum braking systems, our company’s staff constantly researches new developments.

    • Our firm offers a variety of product categories to its clients, using various drum diameters and liner widths.

Main data

Drum diameter x Lining width / [mm] x [mm]   Ø228 x 40

Lining thickness / [mm]   4,15

Hand brake ratio   6,85

Wheel cylinder diameter / [mm]   Ø22,2

Wheel cylinder housing material   Aluminum

Weight / [g]   2700

Adjuster mechanism   Automatic & Bi-metal

Main data

Drum diameter x Lining width / [mm] x [mm]   Ø280 x 55

Lining thickness / [mm]   7

Brake factor (C*)   2,617

Hand brake ratio   7,86

Wheel cylinder diameter / [mm]   Ø25,4

Wheel cylinder housing material   GG 25

Weight / [g]   5350

Adjuster mechanism   Automatic & Bi-metal

Main data

Drum diameter x Lining width / [mm] x [mm]   Ø228 x 55

Lining thickness / [mm]   4,5

Brake factor (C*)   2,4

Hand brake ratio   5,2

Wheel cylinder diameter / [mm]   Ø20,64

Wheel cylinder housing material   Aluminum

Weight / [g]   2870

Adjuster mechanism   Automatic & Bi-metal

Main data

Drum diameter x Lining width / [mm] x [mm]   Ø228 x 40

Lining thickness / [mm]   4,5

Brake factor (C*)   2,3

Hand brake ratio   5,2

Wheel cylinder diameter / [mm]   Ø20,64

Wheel cylinder housing material   GG 25

Weight / [g]   2797

Adjuster mechanism   Automatic & Bi-metal
